5G Outdoor Internet Hotspot v2 - View 1
1 / 2
NEW

5G Outdoor Internet Hotspot v2

Starting from ₹27,000

5G Outdoor Internet Hotspot v2 is an IP68-rated outdoor 5G ODU delivering high-speed wireless broadband using 5G NR SA/NSA and LTE networks, ideal for last-mile connectivity, enterprises, and industrial outdoor deployments.

Need bulk pricing or technical details? Contact us

KEY FEATURES

  • Wireless
  • Cellular
  • DC powered

Description

The 5G Outdoor Internet Hotspot v2 is a high-performance outdoor 5G ODU designed to extend ultra-fast wireless broadband to outdoor, remote, and industrial environments. Built with an IP68 waterproof and dust-proof enclosure and a metal heat-dissipation base, it ensures stable 24×7 operation even in harsh weather conditions. Supporting 5G NR (SA & NSA), 5G RedCap, TDD-LTE, and FDD-LTE networks, the device converts cellular connectivity into high-speed Ethernet output, making it ideal for last-mile broadband, smart cities, campuses, warehouses, and enterprise networks. The unit features high-gain built-in antennas for superior signal acquisition, dual SIM redundancy for uninterrupted connectivity, and PoE or DC power options for flexible outdoor installation. With advanced routing features such as VPN, QoS, TR069 remote management, frequency locking, and firewall protection, the 5G Outdoor Internet Hotspot v2 is engineered for scalable, reliable, and secure outdoor network deployments.

Specification

Cellular & Network Specifications

  • Supported Networks: 5G NR (SA & NSA), 5G RedCap, TDD-LTE, FDD-LTE
  • 5G Frequency Bands: Sub-6GHz bands (region dependent)
  • LTE Bands: LTE FDD, LTE TDD, LAA, WCDMA (region dependent)
  • SIM Support: Dual Nano-SIM (1 Main + 1 Backup)

Performance

  • Theoretical Throughput: Up to multi-Gbps (5G Sub-6, module dependent)
  • Antenna Type: High-gain built-in antennas for long-range signal acquisition

Interfaces

  • Ethernet Port: 1 × Gigabit Ethernet (RJ45)
  • Power Interface: PoE (802.3af) and DC input supported
  • Reset: Hardware reset to factory defaults

Hardware

  • Processor: Industrial-grade quad-core CPU
  • System Design: Watchdog-enabled for continuous stable operation

Power & Environmental

  • Power Supply: PoE (802.3af) or DC power input
  • Operating Temperature: -20°C to +60°C
  • Storage Temperature: -40°C to +85°C
  • Humidity: Up to 95% non-condensing

Mechanical & Protection

  • Enclosure: ABS + metal base enclosure
  • Ingress Protection: IP68 waterproof & dust-proof
  • Dimensions: Approx. 150 × 100 × 240 mm
  • Weight: ≤ 1 kg
  • Mounting Options: Pole-mounted, wall-mounted, bracket installation

Software & Management

  • Operating System: Commercial-grade routing OS
  • Remote Management: TR069, DDNS, web-based UI
  • Security Features: Firewall, VPN, frequency lock, network lock, QoS
  • Monitoring: Traffic statistics and diagnostics

Shipping & Delivery

  • Orders are usually processed within 1–2 business days.
  • Standard delivery time is 5–7 business days, depending on your location.
  • Tracking details will be shared once your order is shipped.
  • For detailed shipping terms, please refer to our Shipping Policy.

Resources

User Manual
Quick Start Guide
Technical Datasheet
Installation Tutorial Video
GUI Installation
Driver Installation
Onboarding with CAN Device
Installation Tutorial Video
GUI Installation
Driver Installation
Onboarding with CAN Device

Frequently Asked Questions

Quick answers to common questions about our products

What is the 5G Outdoor Internet Hotspot v2?

The 5G Outdoor Internet Hotspot v2 is a rugged outdoor 5G ODU that converts cellular 5G and LTE networks into high-speed Ethernet connectivity for outdoor and industrial broadband deployments.

Is this device suitable for outdoor installation?

Yes. The device features an IP68-rated waterproof and dust-proof enclosure with a metal heat-dissipation base, making it ideal for harsh outdoor environments.

What power options are supported?

The hotspot supports both PoE (802.3af) and DC power input, providing flexible installation options depending on site requirements.

Does it support dual SIM for redundancy?

Yes. It includes dual Nano-SIM slots (main and backup) to ensure uninterrupted connectivity in case of network failure.

How is the device installed?

The device supports pole mounting and wall mounting using standard outdoor brackets, making it easy to deploy on towers, buildings, or utility poles.

Can it be used for last-mile broadband?

Absolutely. The 5G Outdoor Internet Hotspot v2 is designed for last-mile wireless access, enterprise connectivity, and extending broadband coverage to remote areas.

What management and security features are available?

It includes VPN support, firewall protection, QoS, frequency locking, network locking, traffic monitoring, and TR069-based remote management.
