5G Indoor Internet Hotspot v2
5G Indoor Internet Hotspot-v2 is a high-performance Wi-Fi 6 CPE that converts 5G and 4G cellular networks into ultra-fast dual-band Wi-Fi and wired internet, ideal for homes, offices, and commercial buildings.
Need bulk pricing or technical details? Contact us
KEY FEATURES
- Wireless
- Cellular
- DC powered
Description
The 5G Indoor Internet Hotspot-v2 is a next-generation indoor connectivity solution designed to deliver ultra-fast, reliable internet using 5G and 4G cellular networks. Built with a powerful quad-core processor and advanced Wi-Fi 6 technology, it transforms cellular data into high-speed dual-band Wi-Fi (2.4GHz + 5GHz) and Gigabit Ethernet connectivity. Supporting both 5G SA and NSA architectures along with LTE-FDD and LTE-TDD, this indoor hotspot ensures broad network compatibility and seamless performance across global deployments. With theoretical download speeds of up to 2.5 Gbps on 5G Sub-6 and robust 4×4 MIMO support, it is well-suited for bandwidth-intensive environments such as offices, smart homes, retail spaces, commercial buildings, airports, and public venues. The device features plug-and-play installation, integrated SIM support, Gigabit LAN/WAN ports, and a compact ABS enclosure optimized for indoor use. Its dual-band Wi-Fi 6 capability ensures improved capacity, lower latency, and stable connections for multiple users and devices. Certified with CE and FCC standards, the 5G Indoor Internet Hotspot-v2 is a reliable and future-ready solution for modern high-speed internet access.
Specification
Cellular Network Specifications
- 5G Support: 5G NR (SA & NSA)
- 4G Support: LTE-FDD & LTE-TDD
- 3G Support: WCDMA
- Network Coverage: 5G / 4G / 3G cellular networks
- Theoretical Max Speed (5G): DL 2.5 Gbps, UL 600 Mbps
- Theoretical Max Speed (LTE): DL 1 Gbps, UL 200 Mbps
Wi-Fi Specifications
- Wi-Fi Standard: Wi-Fi 6 (IEEE 802.11 a/b/g/n/ac/ax)
- Wi-Fi Bands: Dual-band 2.4GHz + 5GHz
- 2.4GHz Speed: Up to 573 Mbps (2×2 MIMO)
- 5GHz Speed: Up to 1.2 Gbps (2×2 MIMO)
- Channel Bandwidth: 20 / 40 / 80 MHz
Hardware Specifications
- Processor: Quad-core processor
- CPU Platform: Industrial-grade chipset
- Flash Memory: 128 MB
- RAM: 512 MB DDR3
Interfaces & Connectivity
- LAN Ports: 1 × Gigabit LAN (RJ45)
- WAN/LAN Port: 1 × Gigabit WAN/LAN (RJ45)
- SIM Slot: Nano-SIM
- USB Port: USB Type-C 2.0
- Indicators: Signal, 5G, 4G, Wi-Fi, Power
- Reset Button: Factory reset supported
Power Specifications
- Power Input: DC 12V / 3A
- Power Range: DC 9V – 24V
- Working Current: < 1.1A @ 12V
- Protection: Built-in reverse power protection
Mechanical & Environmental
- Enclosure Material: ABS Plastic
- Dimensions: 178 × 99 × 99 mm
- Weight: 638 g
- Operating Temperature: 0°C to +45°C
- Storage Temperature: -40°C to +85°C
- Humidity: 95% (non-condensing)
Certifications & Compliance
- Certifications: CE, FCC
Typical Applications
- Use Cases: Homes, offices, smart homes, commercial buildings, retail spaces
- Public Areas: Airports, railway stations, malls, shared workspaces
Shipping & Delivery
- Orders are usually processed within 1–2 business days.
- Standard delivery time is 5–7 business days, depending on your location.
- Tracking details will be shared once your order is shipped.
- For detailed shipping terms, please refer to our Shipping Policy.
Resources
No resources available for this product yet.
Frequently Asked Questions
Quick answers to common questions about our products
What is the 5G Indoor Internet Hotspot-v2?
It is an indoor 5G Wi-Fi 6 CPE that converts 5G and 4G cellular connectivity into high-speed dual-band Wi-Fi and Gigabit Ethernet for homes and commercial spaces.
Does it support both 5G SA and NSA networks?
Yes, the device supports both Standalone (SA) and Non-Standalone (NSA) 5G architectures, ensuring compatibility with modern 5G deployments.
How fast is the internet speed?
The hotspot supports theoretical speeds up to 2.5 Gbps on 5G Sub-6 and up to 1 Gbps on LTE, depending on network conditions.
How is the device installed?
Installation is plug-and-play. Insert a Nano-SIM, connect the power adapter, and access the internet instantly via Wi-Fi or Ethernet.
Can it be wall-mounted or placed on a desk?
Yes, the compact indoor design allows flexible placement on desks, shelves, or wall-mounted locations for optimal signal reception.
How many devices can connect simultaneously?
With Wi-Fi 6 technology and dual-band support, the hotspot can efficiently handle multiple devices simultaneously with stable performance.
Is it suitable for offices and commercial buildings?
Absolutely. It is designed for offices, retail spaces, smart homes, and commercial environments requiring reliable high-speed wireless internet.
Does it require any technical configuration?
Basic operation requires no advanced configuration. Optional settings can be managed via the web interface for advanced networking needs.
