5G Bullet Network Camera

Starting from ₹38,000

Industrial-grade 5G bullet network camera with ultra-low latency HD video, edge AI support, RS232/RS485 interfaces, and IP67 protection for smart city, factory, and outdoor surveillance applications.

Need bulk pricing or technical details? Contact us

KEY FEATURES

  • Wireless
  • Shockproof
  • Remote Control
  • Cellular
  • Bullet Design

Description

The 5G Bullet Network Camera is an industrial-grade IoT surveillance solution designed for high-speed, low-latency video transmission in demanding environments. Powered by an industrial processor and 5G/4G connectivity, it delivers ultra-high-definition video with advanced edge intelligence, wide dynamic range imaging, and robust environmental protection. With integrated RS232 and RS485 interfaces, embedded RTU functionality, and support for AI-based video analytics, this camera is ideal for smart cities, industrial automation, traffic monitoring, critical infrastructure security, and large-scale IoT deployments. Its rugged IP67 metal enclosure, wide temperature tolerance, remote management capabilities, and flexible mounting options ensure reliable 24×7 operation in outdoor and industrial installations.

Specification

Camera & Imaging

  • Image Sensor: 1/2.8-inch Progressive Scan CMOS
  • Maximum Resolution: 1920 × 1080 (Full HD)
  • Minimum Illumination: 0.002 Lux (Color), 0 Lux with IR On
  • Shutter Speed: 1/100000s to 1/5s
  • Infrared Distance: Up to 150 meters
  • Wide Dynamic Range: Up to 140 dB Super WDR
  • Day/Night Mode: ICR Auto Switch

Lens Options

  • Fixed Lens: 2.8 mm @ F2.0
  • Motorized Zoom Lens: 16× AF Motorized Lens (Optional)
  • Field of View: Up to 123° Horizontal (Lens dependent)

Video & Compression

  • Video Compression: H.265 (HEVC), H.264, MJPEG
  • Frame Rate: Up to 30 fps at Full HD
  • Bit Rate: 16 Kbps to 16 Mbps (CBR/VBR Adjustable)
  • Image Controls: Brightness, Contrast, Saturation, Sharpness

Network & Connectivity

  • Cellular Network: 5G NR (SA & NSA), 4G LTE FDD/TDD (Optional)
  • Ethernet Port: 1 × RJ45 10/100 Mbps
  • Supported Protocols: IPv4/IPv6, TCP, UDP, RTP, RTSP, HTTP/HTTPS, SNMP, NTP
  • Network Storage: NAS Support (NFS, SMB/CIFS)

Interfaces & I/O

  • Serial Interfaces: RS232, RS485
  • Digital Inputs / Outputs: 2 × DI, 2 × DO (Optional)
  • Relay Outputs: 2 × Relay (Optional)
  • Audio I/O: 1 Input / 1 Output (Optional)
  • ADC: 2 × 12-bit ADC

Storage & Analytics

  • Local Storage: MicroSD / SDHC / SDXC up to 128 GB
  • AI Video Analytics: Motion Detection, Line Crossing, Intrusion, People Counting (Optional)
  • Event Actions: FTP Upload, Email Alerts, SD Card Recording

Power & Environmental

  • Power Supply: PoE (802.3at) or DC 12–60 V
  • Power Consumption: < 9 W (Max)
  • Operating Temperature: -35 °C to +75 °C
  • Ingress Protection: IP67 Weatherproof

Mechanical & Installation

  • Enclosure: Industrial Metal Housing
  • Dimensions: 260 × 130 × 110 mm
  • Weight: Approx. 4.5 kg
  • Mounting Options: Pole Mount, Wall Mount, DIN Rail (Optional Accessories)

Security & Management

  • Remote Management: Web UI, HTTPS, SSH, SNMP, SYSLOG
  • System Protection: Watchdog, Over-voltage & Reverse Polarity Protection
  • Standards Compliance: ONVIF Profile S, GB/T28181, MQTT, Modbus RTU

Shipping & Delivery

  • Orders are usually processed within 1–2 business days.
  • Standard delivery time is 5–7 business days, depending on your location.
  • Tracking details will be shared once your order is shipped.
  • For detailed shipping terms, please refer to our Shipping Policy.

Resources

User Manual
Quick Start Guide
Technical Datasheet
Installation Tutorial Video
GUI Installation
Driver Installation
Onboarding with CAN Device
Installation Tutorial Video
GUI Installation
Driver Installation
Onboarding with CAN Device

Frequently Asked Questions

Quick answers to common questions about our products

What is the 5G Bullet Network Camera used for?

The 5G Bullet Network Camera is designed for industrial and outdoor surveillance applications such as smart cities, traffic monitoring, factories, critical infrastructure, and large-scale IoT security deployments.

Does the camera support both 5G and 4G networks?

Yes, the camera supports 5G NR (SA & NSA) and 4G LTE networks, ensuring reliable connectivity across different regions and network availability.

Can this camera operate in harsh outdoor environments?

Yes, it features an IP67-rated industrial metal enclosure, wide temperature tolerance, and surge protection, making it suitable for continuous outdoor and industrial use.

Does the camera support AI-based video analytics?

Yes, optional AI analytics such as motion detection, intrusion detection, line crossing, and people counting are supported at the edge for faster response and reduced bandwidth usage.

What installation options are available?

The camera supports pole mounting, wall mounting, and optional DIN rail installation using compatible industrial brackets and accessories.

Can I integrate external sensors with this camera?

Yes, the camera includes RS232 and RS485 interfaces along with digital I/O and relay options, allowing integration with industrial sensors and control systems.

Is remote management and firmware upgrade supported?

Yes, the camera supports secure remote management via web interface, SSH, HTTPS, SNMP, and allows remote firmware upgrades.
