LoRaWAN Sensor Terminal

Starting from ₹10,580

LoRaWAN Sensor Terminal for industrial IoT enables long-range wireless sensor data acquisition with ultra-low power consumption, IP67 protection, and multi-sensor connectivity for smart cities, factories, and environmental monitoring.

Need bulk pricing or technical details? Contact us

KEY FEATURES

  • Wireless
  • Serial
  • Ethernet
  • Remote Control

Description

The LoRaWAN Sensor Terminal is an industrial-grade wireless data acquisition device designed for reliable long-range sensor connectivity in harsh outdoor and industrial environments. Built on LoRa and LoRaWAN technology, it supports multiple sensor interfaces including RS232, RS485, digital I/O, and analog inputs, enabling seamless integration with temperature, pressure, water level, and environmental sensors. With an IP67-rated enclosure, ultra-low power design, and flexible power options including battery and DC input, the terminal is ideal for smart cities, industrial automation, environmental monitoring, and remote asset management. Support for LoRaWAN protocol ensures secure, scalable, and low-latency data transmission over long distances, making it suitable for both private and public IoT networks.

Specification

Wireless Communication

  • Frequency Bands: 433 / 470 / 868 / 915 MHz
  • Communication Protocol: LoRaWAN® and private LoRa protocol
  • Indoor Range: Penetrates up to 10 floors
  • Outdoor Range: Up to 5 km (line of sight)

Sensor & Interface Support

  • Serial Interfaces: RS232, RS485
  • Digital I/O: 2 × Digital Input / Output (0–3.3V)
  • Analog Inputs: 2 × Analog Inputs (0–5V / 0–20mA)
  • Optional Sensor Support: PT100 temperature sensor (optional)

Power & Consumption

  • Power Options: Built-in lithium battery or DC power adapter
  • Battery Capacity (Battery Variant): 3.6V / 19000 mAh
  • DC Input (Powered Variant): 5–36V DC (12V recommended)
  • Sleep Mode Current: < 14 µA

Hardware

  • Processor: Industrial-grade 32-bit communication processor
  • Flash Memory: 128 KB
  • SRAM: 16 KB

Environmental & Mechanical

  • Operating Temperature: -35°C to +75°C (variant dependent)
  • Enclosure Material: PC + ABS, UV resistant, anti-aging
  • Ingress Protection: IP67 waterproof and dustproof
  • Dimensions: 130 × 64 × 64 mm (excluding antenna)
  • Mounting Options: Wall mount (default), DIN-rail, pole mount
  • Flame Rating: UL94V-0

Shipping & Delivery

  • Orders are usually processed within 1–2 business days.
  • Standard delivery time is 5–7 business days, depending on your location.
  • Tracking details will be shared once your order is shipped.
  • For detailed shipping terms, please refer to our Shipping Policy.

Resources

User Manual
Quick Start Guide
Technical Datasheet
Installation Tutorial Video
GUI Installation
Driver Installation
Onboarding with CAN Device
Installation Tutorial Video
GUI Installation
Driver Installation
Onboarding with CAN Device

Frequently Asked Questions

Quick answers to common questions about our products

What is a LoRaWAN Sensor Terminal used for?

A LoRaWAN Sensor Terminal is used to collect data from industrial and environmental sensors and transmit it wirelessly over long distances using LoRaWAN technology. It is widely used in smart cities, factories, environmental monitoring, and remote asset tracking.

Which sensors can be connected to this terminal?

The terminal supports RS232 and RS485 sensors, digital I/O devices, and analog sensors including voltage and current-based sensors such as temperature, pressure, and water level sensors.

Does the device support battery operation?

Yes, the LoRaWAN Sensor Terminal is available in a battery-powered variant with a high-capacity lithium battery designed for multi-year operation using ultra-low power consumption.

How is the device installed?

The device supports wall mounting by default and can optionally be installed using DIN-rail or pole-mounted brackets, making it suitable for indoor and outdoor deployments.

Is this device suitable for outdoor use?

Yes, the terminal features an IP67-rated enclosure that provides full protection against dust and water ingress, making it ideal for harsh outdoor environments.

Does it support public LoRaWAN networks?

Yes, the terminal supports standard LoRaWAN protocol, allowing it to connect to both private gateways and public LoRaWAN network servers.

What power supply options are available?

The terminal is available in two variants: a battery-powered model for remote deployments and a DC-powered model that supports 5–36V input for fixed installations.
