LoRa Edge Gateway

Starting from ₹26,400

LoRa Edge Gateway is a compact industrial IoT gateway that combines LoRaWAN connectivity with 4G/5G networking and edge computing, enabling secure data acquisition, protocol conversion, and real-time cloud integration for smart factories, utilities, and industrial automation.

Need bulk pricing or technical details? Contact us

KEY FEATURES

  • Wireless
  • Serial
  • Ethernet
  • Remote Control
  • Industrial Automation

Description

LoRa Edge Gateway is a high-performance industrial edge gateway designed for reliable IoT data acquisition, protocol conversion, and edge computing. It supports LoRaWAN communication along with 4G and 5G cellular connectivity, enabling seamless integration between field devices such as PLCs, smart meters, and sensors and cloud platforms. Built on an industrial-grade ARM processor with a metal IP30 enclosure, the gateway ensures stable 24x7 operation in harsh environments. With support for RS232, RS485, Ethernet, WiFi, VPN security, remote management, and over 100 industrial protocols including Modbus and OPC UA, it is ideal for smart manufacturing, energy management, smart cities, and industrial IoT deployments.

Specification

Cellular & Network Connectivity

  • Cellular Support: 4G LTE, 5G RedCap (module dependent)
  • Network Modes: LTE-FDD, LTE-TDD, 5G NR, CAT-1 options
  • Dual SIM Support: 2× Nano SIM or eSIM
  • WiFi: 2.4GHz WiFi with WPA/WPA2 encryption
  • Ethernet: 1× WAN/LAN + 1× LAN (10/100 Mbps)
  • Failover: Intelligent dual-link switching between cellular and WAN

LoRa Communication

  • Frequency Bands: 433 / 470 / 780 / 868 / 915 MHz
  • Communication Distance (Urban): Up to 2 km
  • Communication Distance (Open Area): Up to 9 km
  • Receiver Sensitivity: -140 dBm
  • TX Power: <30 dBm
  • LoRa Data Rate: 0.3–5.5 Kbps (6-level adjustable)

Hardware System

  • Processor: Industrial-grade ARM Cortex-A7 @ 1.2GHz
  • RAM: 128 MB DDR3
  • Flash Storage: 128 MB
  • Watchdog: Hardware watchdog for system stability

Interfaces

  • Serial Ports: RS232 + RS485 (configurable)
  • Digital Interfaces: Supports multiple I/O and protocol connections
  • Antenna Interfaces: Cellular, LoRa, WiFi (SMA)
  • Reset: Pinhole reset button

Security & Management

  • VPN Support: PPTP, L2TP, GRE, IPSec, OpenVPN
  • Firewall: SPI Firewall, NAT, DMZ, Access Control
  • Remote Management: SNMP, SYSLOG, SSH, HTTPS, TELNET
  • Cloud Integration: MQTT, HTTPS, TCP/UDP, Industrial IoT platforms

Mechanical & Environmental

  • Enclosure: Metal housing, IP30 protection
  • Dimensions: 99 × 73 × 27 mm
  • Weight: 247 g
  • Operating Temperature: -35°C to +75°C
  • Storage Temperature: -40°C to +85°C
  • Mounting Options: DIN-rail or wall mount

Power

  • Input Voltage: DC 9–36V
  • Typical Consumption: <3W (LTE mode)
  • Protections: Over-voltage, reverse polarity protection

Shipping & Delivery

  • Orders are usually processed within 1–2 business days.
  • Standard delivery time is 5–7 business days, depending on your location.
  • Tracking details will be shared once your order is shipped.
  • For detailed shipping terms, please refer to our Shipping Policy.

Resources

User Manual
Quick Start Guide
Technical Datasheet
Installation Tutorial Video
GUI Installation
Driver Installation
Onboarding with CAN Device
Installation Tutorial Video
GUI Installation
Driver Installation
Onboarding with CAN Device

Frequently Asked Questions

Quick answers to common questions about our products

What is a LoRa Edge Gateway used for?

LoRa Edge Gateway is used to collect data from LoRa sensors and industrial devices, perform edge computing and protocol conversion, and securely transmit data to cloud platforms over 4G or 5G networks.

Does this gateway support both LoRaWAN and cellular connectivity?

Yes, the gateway supports LoRaWAN communication for sensor networks along with 4G LTE and 5G cellular connectivity for backhaul and cloud integration.

Which industrial protocols are supported?

The gateway supports more than 100 industrial protocols including Modbus RTU/TCP, OPC UA, Mitsubishi, and other mainstream PLC and IoT protocols.

How is the LoRa Edge Gateway installed?

The gateway supports DIN-rail and wall-mounted installation, making it easy to deploy inside control panels, cabinets, or industrial enclosures.

Is the device suitable for harsh industrial environments?

Yes, it features an industrial-grade ARM processor, metal enclosure, wide temperature range, watchdog protection, and isolation safeguards for stable 24x7 operation.

Can the gateway work with cloud platforms?

Yes, it supports MQTT over SSL/TLS, HTTPS, TCP/UDP, and can integrate with industrial IoT and cloud platforms for monitoring, analytics, and remote management.

Does it support VPN and secure remote access?

The gateway supports multiple VPN protocols including IPSec, OpenVPN, PPTP, and L2TP to ensure secure data transmission and remote access.
